NGC 6397 - Globular Cluster in Ara

Below the horizon.  Never rises today
Alt: -20.62°   Az: 204.53°   Direction: South-South-West

NGC 6397 is a Globular Cluster in the Ara constellation. NGC 6397 is situated south of the celestial equator and, as such, it is more easily visible from the southern hemisphere. Given its visual magnitude of 5.17, NGC 6397 is barely visible to the naked eye, easily visible with the help of a small binocular.

The image below is a photograph of NGC 6397 from the Digitized Sky Survey 2 (DSS2 - see the credits section) taken in the red channel. The area of sky represented in the image is 0.5100x0.5100 degrees (30.60x30.60 arcmins).

Image of NGC 6397 - Globular Cluster in Ara star
/>
DSS2 image of NGC 6397 in the Red band. The green region on the image is a representation of the major (15.3 arcmin) and minor (15.3 arcmin) axes of the object's apparent size.

Celestial Coordinates

Apparent

17h 42m 45s
-53° 41’ 05”
02h 44m 03s
20h 26m 48s

J2000

17h 40m 41s
-53° 40’ 24”

Finder Chart

The simplified sky charts below show the position of NGC 6397 in the sky. The first chart has a field of view of 60° while the second one has a field of view of 10°.

loader
  Loading map...
Finder chart for NGC 6397 - Globular Cluster in Ara.

loader
  Loading map...
Finder chart for NGC 6397 - Globular Cluster in Ara.

Photometric Information

The following table lists the magnitude of NGC 6397 in different bands of the electomagnetic spectrum (when available), from the B band (445nm wavelength, corresponding to the Blue color), to the V band ( 551nm wavelength, corresponding to Green/Yellow color), to the J, H, K bands (corresponding to 1220nm, 1630nm, 2190nm wavelengths respectively, which are colors not visible to the human eye).

7.39
5.17
3.29

For more information about photometry in astronomy, check the photometric system article on Wikipedia.

Apparent Size

The following table reports NGC 6397 apparent angular size. The green area displayed on top of the DSS2 image of NGC 6397 is a visual representation of it.
15.3 arcmin
15.3 arcmin

Rise and Set Times

Location: Greenwich, UK
Latitude: 51° 28’ 47” N
Longitude: 0° 00’ 00” E
Timezone: Europe/London

NGC 6397 - Globular Cluster in Ara is currently not visible from Greenwich, UK
