NGC 7764 - Barred Spiral Galaxy in Phoenix

Altitude: -57.9°   Azimuth: 88.2°   Direction: East

NGC 7764 is a Barred Spiral Galaxy in the Phoenix constellation. NGC 7764 is situated south of the celestial equator and, as such, it is more easily visible from the southern hemisphere.

The image below is a photograph of NGC 7764 from the Digitized Sky Survey 2 (DSS2 - see the credits section) taken in the red channel. The area of sky represented in the image is 0.5x0.5 degrees (30x30 arcmins).

Image of NGC 7764 - Barred Spiral Galaxy in Phoenix star
/>
DSS2 image of NGC 7764 in the Red band. The green region on the image is a representation of the major (1.95 arcmin) and minor (1.45 arcmin) axes of the object's apparent size.

Key facts about NGC 7764

NGC 7764
Galaxy
Phoenix

NGC 7764 is below the horizon from Greenwich, United Kingdom edit_location_alt.

Altitude: -57.9°
Azimuth: 88.2°
Direction: East

See also NGC 7764 rise and set times.

Given its visual magnitude of 12.3, NGC 7764 is visible with the help of a telescope having an aperture of 8 inches (200mm) or more.

Available Resources for NGC 7764 - Barred Spiral Galaxy in Phoenix

Photometric information of NGC 7764

The following table lists the magnitude of NGC 7764 in different bands of the electomagnetic spectrum (when available), from the B band (445nm wavelength, corresponding to the Blue color), to the V band ( 551nm wavelength, corresponding to Green/Yellow color), to the J, H, K bands (corresponding to 1220nm, 1630nm, 2190nm wavelengths respectively, which are colors not visible to the human eye).

12.97
12.3
11.08
10.56
10.31

For more information about photometry in astronomy, check the photometric system article on Wikipedia.

The surface brightess reported below is an indication of the brightness per unit of angular area of NGC 7764.

22.56 mag/arcsec2

Apparent size of NGC 7764

The following table reports NGC 7764 apparent angular size. The green area displayed on top of the DSS2 image of NGC 7764 is a visual representation of it.
1.95 arcmin
1.45 arcmin
146°

NGC 7764 - Barred Spiral Galaxy in Phoenix morphological classification

NGC 7764 - Barred Spiral Galaxy in Phoenix is classified as Barred Spiral (Bm) according to the Hubble and de Vaucouleurs galaxy morphological classification. The diagram below shows a visual representation of the position of NGC 7764 - Barred Spiral Galaxy in Phoenix in the Hubble de Vaucouleurs sequence.

NGC 7764 - Barred Spiral Galaxy in Phoenix
Visualization of the morphological classification of NGC 7764 - Barred Spiral Galaxy in Phoenix, Barred Spiral (Bm).
Credits for the background image: Antonio Ciccolella / M. De Leo / CC BY

Celestial coordinates and finder chart of NGC 7764

Celestial coordinates for the J2000 equinox of NGC 7764 are provided in the following table:

23h 50m 53s
-40° 43’ 41”

The simplified sky charts below show the position of NGC 7764 in the sky. The first chart has a field of view of 60° while the second one has a field of view of 10°.

Finder chart NGC 7764 - Barred Spiral Galaxy in Phoenix star
Simplified finder chart for NGC 7764 - Barred Spiral Galaxy in Phoenix.

Finder chart NGC 7764 - Barred Spiral Galaxy in Phoenix star
Simplified finder chart for NGC 7764 - Barred Spiral Galaxy in Phoenix.

Rise and set times of NGC 7764 from your location

Location: Greenwich, United Kingdom edit_location_alt
Latitude: 51° 28’ 47” N
Longitude: 0° 00’ 00” E
Timezone: Europe/London

NGC 7764 - Barred Spiral Galaxy in Phoenix is currently not visible from Greenwich, United Kingdom edit_location_alt
